LevelDB | 0x01 基本工具和数据结构

void CreateFilter(const Slice* keys, int n, std::string* dst) const override {
  // Compute bloom filter size (in both bits and bytes)
  size_t bits = n * bits_per_key_;

  // For small n, we can see a very high false positive rate.  Fix it
  // by enforcing a minimum bloom filter length.
  if (bits < 64) bits = 64;

  size_t bytes = (bits + 7) / 8;
  bits = bytes * 8;

  const size_t init_size = dst->size();
  dst->resize(init_size + bytes, 0);
  dst->push_back(static_cast<char>(k_));  // Remember # of probes in filter
  char* array = &(*dst)[init_size];
  for (int i = 0; i < n; i++) {
    // Use double-hashing to generate a sequence of hash values.
    // See analysis in [Kirsch,Mitzenmacher 2006].
    uint32_t h = BloomHash(keys[i]);
    const uint32_t delta = (h >> 17) | (h << 15);  // Rotate right 17 bits
    for (size_t j = 0; j < k_; j++) {
      const uint32_t bitpos = h % bits;
      array[bitpos / 8] |= (1 << (bitpos % 8));
      h += delta;
    }
  }
}

bool KeyMayMatch(const Slice& key, const Slice& bloom_filter) const override {
  const size_t len = bloom_filter.size();
  if (len < 2) return false;

  const char* array = bloom_filter.data();
  const size_t bits = (len - 1) * 8;

  // Use the encoded k so that we can read filters generated by
  // bloom filters created using different parameters.
  const size_t k = array[len - 1];
  if (k > 30) {
    // Reserved for potentially new encodings for short bloom filters.
    // Consider it a match.
    return true;
  }

  uint32_t h = BloomHash(key);
  const uint32_t delta = (h >> 17) | (h << 15);  // Rotate right 17 bits
  for (size_t j = 0; j < k; j++) {
    const uint32_t bitpos = h % bits;
    if ((array[bitpos / 8] & (1 << (bitpos % 8))) == 0) return false;
    h += delta;
  }
  return true;
}

class HandleTable {
 public:
  HandleTable() : length_(0), elems_(0), list_(nullptr) { Resize(); }
  ~HandleTable() { delete[] list_; }

  LRUHandle* Lookup(const Slice& key, uint32_t hash) {
    return *FindPointer(key, hash);
  }

  LRUHandle* Insert(LRUHandle* h) {
    LRUHandle** ptr = FindPointer(h->key(), h->hash);
    LRUHandle* old = *ptr;
    h->next_hash = (old == nullptr ? nullptr : old->next_hash);
    *ptr = h;
    if (old == nullptr) {
      ++elems_;
      if (elems_ > length_) {
        // Since each cache entry is fairly large, we aim for a small
        // average linked list length (<= 1).
        Resize();
      }
    }
    return old;
  }

  LRUHandle* Remove(const Slice& key, uint32_t hash) {
    LRUHandle** ptr = FindPointer(key, hash);
    LRUHandle* result = *ptr;
    if (result != nullptr) {
      *ptr = result->next_hash;
      --elems_;
    }
    return result;
  }

 private:
  // The table consists of an array of buckets where each bucket is
  // a linked list of cache entries that hash into the bucket.
  uint32_t length_;
  uint32_t elems_;
  LRUHandle** list_;

  // Return a pointer to slot that points to a cache entry that
  // matches key/hash.  If there is no such cache entry, return a
  // pointer to the trailing slot in the corresponding linked list.
  LRUHandle** FindPointer(const Slice& key, uint32_t hash) {
    LRUHandle** ptr = &list_[hash & (length_ - 1)];
    while (*ptr != nullptr && ((*ptr)->hash != hash || key != (*ptr)->key())) {
      ptr = &(*ptr)->next_hash;
    }
    return ptr;
  }

  void Resize() {
    uint32_t new_length = 4;
    while (new_length < elems_) {
      new_length *= 2;
    }
    LRUHandle** new_list = new LRUHandle*[new_length];
    memset(new_list, 0, sizeof(new_list[0]) * new_length);
    uint32_t count = 0;
    for (uint32_t i = 0; i < length_; i++) {
      LRUHandle* h = list_[i];
      while (h != nullptr) {
        LRUHandle* next = h->next_hash;
        uint32_t hash = h->hash;
        LRUHandle** ptr = &new_list[hash & (new_length - 1)];
        h->next_hash = *ptr;
        *ptr = h;
        h = next;
        count++;
      }
    }
    assert(elems_ == count);
    delete[] list_;
    list_ = new_list;
    length_ = new_length;
  }
};

class SkipList {
  ...
 private:
  ...
  // Immutable after construction
  Comparator const compare_;
  Arena* const arena_;  // Arena used for allocations of nodes

  Node* const head_;

  // Modified only by Insert().  Read racily by readers, but stale
  // values are ok.
  std::atomic<int> max_height_;  // Height of the entire list

  // Read/written only by Insert().
  Random rnd_;

template <typename Key, class Comparator>
struct SkipList<Key, Comparator>::Node {
  ...
  Key const key;
  ...

 private:
  // Array of length equal to the node height.  next_[0] is lowest level link.
  std::atomic<Node*> next_[1];
};

template <typename Key, class Comparator>
typename SkipList<Key, Comparator>::Node* SkipList<Key, Comparator>::NewNode(
    const Key& key, int height) {
  char* const node_memory = arena_->AllocateAligned(
      sizeof(Node) + sizeof(std::atomic<Node*>) * (height - 1));
  return new (node_memory) Node(key);
}

template <typename Key, class Comparator>
void SkipList<Key, Comparator>::Insert(const Key& key) {
  // TODO(opt): We can use a barrier-free variant of FindGreaterOrEqual()
  // here since Insert() is externally synchronized.
  Node* prev[kMaxHeight];
  Node* x = FindGreaterOrEqual(key, prev);

  // Our data structure does not allow duplicate insertion
  assert(x == nullptr || !Equal(key, x->key));

  int height = RandomHeight();
  if (height > GetMaxHeight()) {
    for (int i = GetMaxHeight(); i < height; i++) {
      prev[i] = head_;
    }
    // 在没有任何同步的情况下修改 max_height_ 是可以的。一个并发的读取者如果观察到 max_height_ 的新值，
    // 要么会看到 head_ 的旧指针值（nullptr），要么会看到下面循环设置的新值。在前一种情况下，读取者会立即
    // 降级到下一个层级，因为 nullptr 排在所有键之后。在后一种情况下，读取者会使用新节点。
    max_height_.store(height, std::memory_order_relaxed);
  }

  x = NewNode(key, height);
  for (int i = 0; i < height; i++) {
    // NoBarrier_SetNext() suffices since we will add a barrier when
    // we publish a pointer to "x" in prev[i].
    x->NoBarrier_SetNext(i, prev[i]->NoBarrier_Next(i));
    prev[i]->SetNext(i, x);
  }
}

template <typename Key, class Comparator>
typename SkipList<Key, Comparator>::Node*
SkipList<Key, Comparator>::FindGreaterOrEqual(const Key& key,
                                              Node** prev) const {
  Node* x = head_;
  int level = GetMaxHeight() - 1;
  while (true) {
    Node* next = x->Next(level);
    if (KeyIsAfterNode(key, next)) {
      // Keep searching in this list
      x = next;
    } else {
      if (prev != nullptr) prev[level] = x;
      if (level == 0) {
        return next;
      } else {
        // Switch to next list
        level--;
      }
    }
  }
}

class LEVELDB_EXPORT Slice {
 public:
  ...
  // Return a pointer to the beginning of the referenced data
  const char* data() const { return data_; }

  // Return the length (in bytes) of the referenced data
  size_t size() const { return size_; }

  // Return true iff the length of the referenced data is zero
  bool empty() const { return size_ == 0; }

  const char* begin() const { return data(); }
  const char* end() const { return data() + size(); }

  // Return the ith byte in the referenced data.
  // REQUIRES: n < size()
  char operator[](size_t n) const;

  // Change this slice to refer to an empty array
  void clear();

  // Drop the first "n" bytes from this slice.
  void remove_prefix(size_t n);
  // Return a string that contains the copy of the referenced data.
  std::string ToString() const;

  // Three-way comparison.  Returns value:
  //   <  0 iff "*this" <  "b",
  //   == 0 iff "*this" == "b",
  //   >  0 iff "*this" >  "b"
  int compare(const Slice& b) const;

  // Return true iff "x" is a prefix of "*this"
  bool starts_with(const Slice& x) const;

 private:
  const char* data_;
  size_t size_;
};

inline bool operator==(const Slice& x, const Slice& y);

inline bool operator!=(const Slice& x, const Slice& y);

inline int Slice::compare(const Slice& b) const ;

class LEVELDB_EXPORT Comparator {
 public:
  virtual ~Comparator();

  // Three-way comparison.  Returns value:
  //   < 0 iff "a" < "b",
  //   == 0 iff "a" == "b",
  //   > 0 iff "a" > "b"
  virtual int Compare(const Slice& a, const Slice& b) const = 0;

  // The name of the comparator.  Used to check for comparator
  // mismatches (i.e., a DB created with one comparator is
  // accessed using a different comparator.
  //
  // The client of this package should switch to a new name whenever
  // the comparator implementation changes in a way that will cause
  // the relative ordering of any two keys to change.
  //
  // Names starting with "leveldb." are reserved and should not be used
  // by any clients of this package.
  virtual const char* Name() const = 0;

  // Advanced functions: these are used to reduce the space requirements
  // for internal data structures like index blocks.

  // If *start < limit, changes *start to a short string in [start,limit).
  // Simple comparator implementations may return with *start unchanged,
  // i.e., an implementation of this method that does nothing is correct.
  virtual void FindShortestSeparator(std::string* start,
                                     const Slice& limit) const = 0;

  // Changes *key to a short string >= *key.
  // Simple comparator implementations may return with *key unchanged,
  // i.e., an implementation of this method that does nothing is correct.
  virtual void FindShortSuccessor(std::string* key) const = 0;
};

class LEVELDB_EXPORT Iterator {
 public:
  ...

  // Clients are allowed to register function/arg1/arg2 triples that
  // will be invoked when this iterator is destroyed.
  //
  // Note that unlike all of the preceding methods, this method is
  // not abstract and therefore clients should not override it.
  using CleanupFunction = void (*)(void* arg1, void* arg2);
  void RegisterCleanup(CleanupFunction function, void* arg1, void* arg2);

 private:
  // Cleanup functions are stored in a single-linked list.
  // The list's head node is inlined in the iterator.
  struct CleanupNode {
    // True if the node is not used. Only head nodes might be unused.
    bool IsEmpty() const { return function == nullptr; }
    // Invokes the cleanup function.
    void Run() {
      assert(function != nullptr);
      (*function)(arg1, arg2);
    }

    // The head node is used if the function pointer is not null.
    CleanupFunction function;
    void* arg1;
    void* arg2;
    CleanupNode* next;
  };
  CleanupNode cleanup_head_;
};
